Major Parameter | |||||
Road Type | Paved road | ||||
Max weight(t) | ≤40 | ||||
Drive Type | 4x2 | ||||
Cruising speed/Max speed | 75-100/110(Km/h) | ||||
Vehicle model | SX4185NT361 | ||||
Rated Load(ton) | 30 | ||||
Capacity of the fuel tank | 400L | ||||
Engine | Frame Specification | ||||
Engine type | WP10.380E32 | Frame(mm) | (940-850)x300 | ||
Emission standard | Euro II | Dimensions(mm) | 6150*2490*4000 | ||
Displacement | 9.72L | Wheel base (mm) | 3600 | ||
Rated Power / rotating | 280Kw/2200rpm | Front Suspension | 1525 | ||
Maximum Torque | 1460Nm | Rear Suspension | 1025 | ||
Fuel type | Diesel | Approach/Departure angel | 20/42 | ||
Transmission | Axle | ||||
Type | 12JS180T | Front axle | MAN 7.5T | ||
Torque | 1800Nm | Disc Brake | |||
Input power | 331Kw | Rear axle | 13T MAN Double | ||
Weight | 350kg | Dump Brake | |||
Oiling quantity | 14.5 | Speed ratio | 4.266/4.769/5.262/5.92 | ||
Cab (MAN F3000, lengthened flat roof) | |||||
Equipments | Two sleeping bed | ||||
Automatic air conditioning | |||||
Mechanical clerestory | |||||
Hydraulic suspension of cab | |||||
Hydraulic driver seat with seatbelts | |||||
radio with MP3 player | |||||
Steering system | 8908 | ||||
Clutch | φ430 | ||||
Tire | 12.00R20 | ||||
Wheels number | 6+1 | ||||
